Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: bls
  • Model Number: JML
  • Type: Grain Processing Equipment
  • After-sales Service Provided: Overseas service center available
  • Application: industrial steel grinding sesame paste miller for sale with control
  • Voltage: 110-480V, 50/60Hz
  • Power: 2.2-18.5kw
  • Speed: 2800rpm
  • Output: 0.02-10T/H(water test)
  • Outlet type: circulation pipe, square type etc.
  • Material: Stainless Steel 304/316L
  • Function: sesame paste grinding mill
  • Usage: Stainless Steel sesame paste grinder
  • Name: industrial steel grinding sesame paste miller for sale with control

Packaging & Delivery

Packaging Details plywood case packing
industrial steel grinding sesame paste miller for sale with control
Delivery Time Shipped in 15 days after payment
Product Description

industrial steel grinding sesame paste miller for sale with control

    JM series colloidal mill is a new-type equipment of wet type super micro grain processing, suitable for the homogenization, emulsification, separation, smash and milling of various emulsions.

    It widely used in foodstuff (fruit jam, juice, albumen milk, soy milk, milk tea, dairy, beverage,etc.), pharmacy, dairy chemical, chemical industry, emulsion asphalt, coal floating agent, ceramic glaze, emulsion detonator, nanometer material, etc.

Name:
industrial steel grinding sesame paste miller for sale with control
Brand name:
L&B
MOQ:
one set
Material:
high-intensity stainless steel 304 and 316L
( ss304 suit acid or alkali weak; ss316 suit acid or alkali a bit strong)
Advantages:
anti-corrosion, anti-abrasion ability, without pollution
Main parts:
grinding head, pedestal driving part and special motor
Grinder types:
solid
Model:
JML
Inlet Dim:
30-66mm, can be in-line type
Outlet Dim:
20-32mm, can be customized as square outlet
Output:
0.01-4T/H
Motor power:
1.1-18.5kw
Speed:
2800rpm
Feed hopper:
4L, 7L, 10L etc
Switch:
≤ 7.5kw
Motor:
ABB is optional
Rotary vane:
V-type head or spiral head
Seal:
oil seal
Machine type:
Wet-type equipment of wet type super micro grain processing
Outlet connection:
union(tri-clamp is optional)
Outlet type:
pipe or square type
Patent:
national invention patent No. 200510123583.8,
international application patent PCT/CN2006/001481.

PRINCIPLE:

    The basic working principle of colloid mill is shearing, grinding as well as high-speed stirring applied force, grinding is finished depending on the relative movement of tooth-form slope, one of them rotates at high speed, while the other stays still to make materials that passing between tooth-form slopes receive great shear force and friction, and to grind, emulsify, smash, homogenize and mix them under complex forces such as high-frequency shake, high-speed vortex and others at the same time, so as to achieve the effect of fine and super micro.

Patent:

    The colloid mill in Our factory has been applied all new technology, which has won national invention patent No. 200510123583.8, the international application patent PCT/CN2006/001481, greatly extend the service life of the colloid mill, and improve the quality of the colloid mill products.

Model
Emulsified size (um)
Output T/h
Millstone Dim(mm)
Outlet Dim(mm)
Inlet Dim(mm)
Speed (rpm)
Power(kw)
JML-50
2-40
0.01-0.1
50
20
30
2800
1.5(220V)
JML-50
2-40
0.01-0.1
50
20
30
2800
1.1(380V)
JML-65
2-40
0.02-0.5
65
20
30
2800
1.5
JML-80
2-40
0.3-1
80
25
48
2800
3
JML-100
2-40
0.5-2
100
25
66
2800
5.5
JML-120
2-40
0.5-3
120
32
66
2800
7.5
JML-140
2-40
0.5-4
140
32
66
2800
7.5

Warranty:

1. Since the acquisition date, the mechanical seal within three-months warranty, and other parts with 12-month warranty under normal circumstances.

2. Beyond the time limit, a paid maintenance service is provided for life. Normal wear is not included.

3.Under warranty,no free repair in any circumstances below:

a. No purchase vouchers(Invoice or Receipt)

b. Damage caused by disassembling or modification

c. Due to the careless error use or improper use man-made damage

d. Under the condition of not usually use(e.g, long time used in harsh place) caused by the fault or damage


e. Product packaging is not complete, the exterior pollution for use

Packing & Delivery
Certifications
Our Company

Zhejiang L&B Fluid Equipment co., Ltd

    a modern enterprise which combine the ability of design, development, manufacturing, engineering, installation, technical services, has special technology to design and exploit by CAD software and computer and is a outstanding leader among valve fields.

    We have advanced CNC lathes imported from Japan.We can manufacture the valves and fitting according to ISO, DIN, IDF, SMS, 3A, while we can produce the products per as the requirement from the clients(non-standard).

    We are specialized in producing different kinds of valves, pipe fitting, tubes, manhole covers, pumps, tanks etc for many years. We can design the products according to your special request. OEM is welcome too.
