steel high shear liquid conditioner homogenizer-mixer

FOB Reference Price:Get Latest Price
US $1,800-6,800 / Sets | 1 Set/Sets steel high shear liquid conditioner homogenizer-mixer (Min. Order)
Model Number:
mixing tank
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Mixer Type:
Homogenizer
Product Type:
Shampoo
Application:
Liquid
Additional Capabilities:
homo mixer
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
BLS
Max. Loading Capacity:
10000L
Voltage:
110V~480V
Power(W):
0.75KW~75KW
Dimension(L*W*H):
Custom Made
Certification:
ISO9001:2008
Warranty:
1year
After-sales Service Provided:
Overseas service center available
Material:
Stainless Steel 304 / SUS316L
Agitator:
homogenizer - mixer
Speed range:
2800rpm
Pressure:
normal pressure
Cover:
flat cover
Jacket:
no jacket, or cooling and heating jacket avaible
Heating method:
steam or electric heater or without
Function:
steel high shear liquid conditioner homogenizer-mixer
Capacity:
50-5000L
Product name:
steel high shear liquid conditioner homogenizer-mixer
Supply Ability
Supply Ability:
200 Unit/Units per Month steel high shear liquid conditioner homogenizer-mixer
Packaging & Delivery
Packaging Details
Plywood case
steel high shear liquid conditioner homogenizer-mixer
Port
Ningbo
Lead Time :
Shipped in 15 days after payment
Product Description

steel high shear liquid conditioner homogenizer-mixer

1. Used as blending tank, mixing tank, preparation tank, fermentation tank, disinfection tank and ageing tank etc.
2. Ideal in fields such as food, dairy products, fruit juice beverages, pharmacy, chemical industry and biological engineering etc.

Structure characteristics:

1.Adopt structure of internal tank and external package, with heat preservation materials inside.
2.Materials are all sanitary stainless steel.
3.Humanized structure design and easy to operate.
4.Transition area of interior wall on tank adopts arc for transition to ensure no dead corner of sanitation.

Configuration of tank:

1)Quick open manhole.
2)Various types of CIF cleaners.
3)Fly and insect resistant sanitary breathing cover.
4)Adjustable triangular bracket.
5)Dismountable materials input pipe assembly.
6)Thermometer (according to customer requirements).
7)Ladder (according to customer requirements).
8)Vertical blender (paddle type or fame type are available if customer require).
9)Jacket (miller board, hollow jacket or coil pipe jacket are available according to customer requirements).
10)Liquid level meter and level controller (according to customer requirements).
11)Eddy-proof board.

    It can be customized according to special requirements of our customers. Total height is computed according to the height (800mm) of the discharge outlet. If the height of discharge outlet is changed, total height shall be adjusted.

Volume (L)
Dimension D*h (mm*mm)
Height (mm)
In/Outlet diameter (mm)
Heat preservation layer
1000
1060*1220
2550
51
60
1500
1160*1500
2850
51
60
2000
1340*1500
2900
51
60
3000
1410*2000
3400
51
60
4000
1620*2000
3450
51
60
5000
1810*2000
3500
51
60
6000
1930*2000
3550
51
60
7000
1930*2440
4000
51
60
8000
2060*2440
4000
51
60
9000
2180*2440
4050
51
60
10000
2300*2440
4050
51
60
12000
2270*3000
4600
51
60
15000
2530*3000
4700
51
60
20000
2640*3660
5400
51
60
Packing & Delivery
Certifications
Our Company

Zhejiang L&B Fluid Equipment co., Ltd

    a modern enterprise which combine the ability of design, development, manufacturing, engineering, installation, technical services, has special technology to design and exploit by CAD software and computer and is a outstanding leader among valve fields.

    We have advanced CNC lathes imported from Japan.We can manufacture the valves and fitting according to ISO, DIN, IDF, SMS, 3A, while we can produce the products per as the requirement from the clients(non-standard).

    We are specialized in producing different kinds of valves, pipe fitting, tubes, manhole covers, pumps, tanks etc for many years. We can design the products according to your special request. OEM is welcome too.

FAQ
Our Service
Please contact our After-sales service department in time within 30days after you received the cargo.
Tel: 86-577-86821328 Time: 9:00 a.m.- 6:00 p.m. (Beijing time)
 Process
Please provide the copy of Sales Contract and describe the problems appeared.
Problems confrimation:
Slight problem:
Please send the proof to our After-Sales Department, we will reply within two days.
Serious problem:
a
We will dispatch our Quality and Problems Appraisers to make a confirmation.
b
Have a negotiation of the compensation and sign agreements
c
Our After-Sales Department will perform the duties as the agreements
