Quick Details

  • Condition: New
  • Mixer Type: Agitator
  • Product Type: Explosion-proof 22kw Vertical agitator mixer for chemical tank
  • Application: Liquid
  • Additional Capabilities: steel disc impeller mixer
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: BLS
  • Model Number: BLS
  • Max. Loading Capacity: 10000L
  • Voltage: 110-480V
  • Power(W): 0.75KW~45KW
  • Dimension(L*W*H): Referring
  • Certification: ISO9001:2008
  • Warranty: 12 Months
  • After-sales Service Provided: Overseas service center available
  • Name: Explosion-proof 22kw Vertical agitator mixer for chemical tank
  • Material: Stainless Steel 304/316
  • Function: chemical liquid mixing machine
  • Capacity: 50-10000L
  • Type: stainless steel disc impeller machine
  • Item: liquid chemical mixing machine
  • Speed: 1460rpm
  • Usage: Explosion-proof 22kw Vertical agitator mixer for chemical tank
  • Machine Type: industrial high speed disc mixer
  • Application scope: Explosion-proof 22kw Vertical agitator mixer for chemical tank

Packaging & Delivery

Packaging Details plywood case package
Explosion-proof 22kw Vertical agitator mixer for chemical tank
Delivery Time 15 days after payment received
Product Description

Explosion-proof 22kw Vertical agitator mixer for chemical tank

    It is a kind of vertical installation of emulsification equipment. Stator design for claw type coupling structure, material from the host upper and lower suction at the same time, and around the centrifugal throw, Shear homogeneous efficiency multiplied, to avoid the problem of kettle inside the upper material is easy to produce blind Angle.

Explosion-proof 22kw Vertical agitator mixer for chemical tank


Characteristics

1. Simple overall structure, small size, light weight.
2. Humanized structure design and easy to operate.
3. Low noise and smooth operation.

Explosion-proof 22kw Vertical agitator mixer for chemical tank


Applicable range

1. Suitable for all kinds of large and small reaction kettle, uniform, fine on the common container, emulsification.
2. Small capacity of emulsion can be used for mobile lifting.
3. Widely applied in food, beverage, chemical, biochemical, petrochemical, pigments, dyes, paints, pharmaceuticals and other industries.

Model
Power
Speed
Length
Capacity
(kw)
(rpm)
(mm)
(L/H)
BRH-80
1.1
2800
350
10~40
BRH-90
1.5
2800
350
10~50
BRH-100
2.2
2800
650
50~100
BRH-120
3
2800
750
100~200
BRH-120A
4
2800
750
100~300
BRH-140
5.5
2800
900
200~600
BRH-140A
7.5
2800
900
200~800
BRH-160
11
2800
1050
500~1500
BRH-180
18.5
2800
1200
600~2000
BRH-200
22
1400
1200
800~2500
BRH-220
30
1400
1355
1000~3500
BRH-240
45
1400
1395
1500~5000
BRH-270
55
1400
1600
2000~8000
BRH-290
75
1400
1650
3000~10000
Certifications
Packing & Delivery
Our Company

Zhejiang L&B Fluid Equipment co., Ltd

    a modern enterprise which combine the ability of design, development, manufacturing, engineering, installation, technical services, has special technology to design and exploit by CAD software and computer and is a outstanding leader among valve fields.

    We have advanced CNC lathes imported from Japan.We can manufacture the valves and fitting according to ISO, DIN, IDF, SMS, 3A, while we can produce the products per as the requirement from the clients(non-standard).

    We are specialized in producing different kinds of valves, pipe fitting, tubes, manhole covers, pumps, tanks etc for many years. We can design the products according to your special request. OEM is welcome too.
